HPE Aruba Instant On 1430 26G 2SFP Switch (Model R8R50A)
The Aruba Instant On 1430 26G 2SFP (R8R50A) is a simple, reliable unmanaged Layer 2 Gigabit Ethernet switch with 26 RJ‑45 ports and 2 SFP uplinks, offering plug‑and‑play connectivity for small businesses, offices, and PoE/AP networks — fan‑less, silent, and easy to deploy.
Description
Aruba Instant On 1430 26G 2SFP Switch (R8R50A) — Unmanaged Gigabit 26‑Port + 2 SFP for SMB
Key Features:
-
26 × 10/100/1000 Mbps RJ‑45 Ports: Auto‑sensing Gigabit Ethernet ports for wired LAN connections.
-
2 × 1 Gb SFP Uplink Ports: Fiber or copper SFP slots support long‑distance uplinks to other switches or core network equipment.
-
Unmanaged / Plug‑and‑Play: No configuration required — ideal for simple deployments where management isn’t needed.
-
Layer 2 Switching: Basic switching with support for flow control and QoS for improved data, VoIP, and video performance.
-
Fan‑less Design: Silent operation suitable for office, meeting room, or desk placement.
-
Auto MDI/MDIX: Eliminates the need for crossover cables; automatically adjusts.
-
Energy Efficient Ethernet: Helps reduce power draw when ports are idle or under light load.
Hardware & Performance:
-
Switching Capacity: ~56 Gbps total fabric.
-
Throughput: ~41.68 million packets per second (Mpps).
-
MAC Address Table: ~16,384 entries.
-
Packet Buffer: ~12 MB.
-
Latency: ~2.9 µs at Gigabit speeds.
-
Power & Consumption: Internal AC power supply with typical max ~16.4 W.
-
Operating Temp: 0 °C to 40 °C (32 °F to 104 °F).
-
Dimensions: ~225 × 388 × 44 mm; Weight: ~2.27 kg.
Technical Datasheet
You can download the full technical documentation for this product from the link below:
Download PDF Datasheet
