ProLink PL-FEC-24 Fiber Optic Sytem

Key Features:

• Up to 48-Core Capacity — Supports up to 48 fiber cores with four splice trays.

• High-Performance Sealing — IP68 waterproof protection keeps moisture and contaminants out.

• Multiple Cable Ports — Four mechanical seal cable ports for flexible fiber entry/exit.

• Durable Construction — Made from high-impact resistant polypropylene (PP) with UV protection.

• Versatile Mounting Options — Can be wall-mounted, pole-mounted, or aerial-hung depending on installation needs.

• Compact Vertical Design — Efficient use of space and easy access for maintenance.

Technical Highlights :

• Brand: ProLink

• Model: PL-FEC-24

• Product Type: Fiber Optic Splice Closure / Fiber System

• Capacity: Up to 48 fiber cores (48 C)

• Splice Trays: 4 trays (each supporting up to 12 cores)

• Cable Ports: 4 mechanical seal ports

• Ingress Protection: IP68 waterproof rating

• Material: Polypropylene (PP) with UV resistance

• Mounting Options: Wall, pole, aerial hanger

• Dimensions: Approx. Φ146 × 310.5 mm

Performance & Connectivity:

• Reliable Environmental Protection — Designed to protect fiber splices from water, dust, and environmental stresses.

• Organized Splice Management — Four trays allow systematic layout of fiber splices with room for expansion.

• Flexible Deployment — Can be deployed in a range of environments such as aerial, wall, or pole installations.
