Name: APC Smart-UPS On-Line, SRTG5KXLI, 5kVA/5kW, Rack/Tower
Brand: Schneider/APC
SKU: SRTG5KXLI

Description

SRTG5KXLI

Specifications

Overview
Lead time	Usually in Stock

Main
Run time for load W information_stroke Min-max: 500-5000 W	2min 50s
Max. Capacity Used information_stroke	100 %
Main Input Voltage	230 V
product or component type	Uninterruptible power supply (UPS)
Other Input Voltage	220 V 240 V
Main Output Voltage	230 V
Other Output Voltage	220 V 240 V
Rated power in W	5000 W
Rated power in VA	5000 VA
output connection type	2 IEC 60320 C13 1 IEC 60320 C19
Output connector type	Hard wire 3-wire (1P + N + E) 1
Number of rack unit	4U
Provided equipment	1 x USB cable 1 x rack mounting brackets 1 x stabilization/wall mounting feet 1 x installation manual 1 x C13-C14 power cord
Range of product	Smart-UPS On-Line

Batteries & Runtime
Run Time	View Runtime Graph
Efficiency	View Efficiency Graph
Battery type	Lead-acid battery
Number of battery filled slots	2
Number of battery free slots	0
Battery recharge time	4 h
Number of battery replacement quantity	1
Battery voltage	+/- 96 V
Battery charger power	239 W rated
Battery life	3…5 year(s)
Replacement battery	APCRBC170
Extended runtime	1

General
UPS type	Double conversion online
Number of power module free slots	0
Number of power module filled slots	0
Redundant	No

Output
Maximum configurable power in VA	5000 VA
Maximum configurable power in W	5000 W
Output frequency	50/60 Hz +/- 4 Hz sync to mains
Wave type	Sine wave
Efficiency	93.5 %
Harmonic distortion	Less than 2 %
Crest factor	3 : 1
Bypass type	Internal bypass (automatic and manual)
Additional information	Configurable for 220 : 230 or 240 nominal output voltage

Conformance
Product certifications	CE UKCA TISI
Standards	EN/IEC 62040-1:2019/A11:2021 EN/IEC 62040-2:2006/AC:2006 EN/IEC 62040-2:2018

Environmental
Ambient air temperature for operation	0…40 °C
Relative humidity	0…95 % non-condensing
Operating altitude	0…3000 m
Ambient air temperature for storage	-15…45 °C
Storage Relative Humidity	0…95 % non-condensing
Storage altitude	0…15000 m
Acoustic level	55 dBA
heat dissipation	1108.95 Btu/h
IP degree of protection	IP20

Communications & Management
Preinstalled device	Network management card 3 with environmental monitoring
Alarm	Alarm when on battery : distinctive low battery alarm : overload continuous tone alarm
Emergency power off	Yes

Surge Protection and Filtering
Surge energy rate	600 J

Contractual warranty
Warranty	3 years repair or replace (excluding battery) and 2 years for battery
