HPE Aruba / JL255A / 2930F / 24 Port Gigabit ( 24 POE – 370 Watts ) & 4 SFP+ 1/10GbE ports managed Switch

SKU: JL255A

Contact us for pricing on this product:

Request Quote by EmailWhatsApp Us
In Stock
EGP 0.00
In Stock

JL255A

Brand:

Description

JL255A

 Overview

Aruba 2930F Switch Series is designed for customer creating digital workplaces optimized for mobile users with an integrated wired and wireless approach. These basic Layer 3 access switches are easy to deploy and manage with advanced security and network management tools like Aruba ClearPass Policy Manager and Aruba AirWave and are ideal for enterprise edge, SMB and branch offices.

A powerful Aruba ProVision ASIC delivers performance and value supporting the latest SDN applications with future proof programmability. The 2930F supports 10GbE uplinks, PoE+, robust QoS, RIP routing, Access OSPF, ACLs, Tunneled Node and IPv6. This JL255A has 24x 10/100/1000 PoE+ ports and 4x 1000/10G SFP+ transceiver slots for high speed connectivity. PoE+ is supported with a power budget of 370 Watts.

Figure 1 shows the front panel of HPE Aruba JL255A.

HPE-Aruba-JL255A-Front-Panel

Note:

①4 x SFP+ 1/10GbE ports
②24 x RJ-45 autosensing 10/100/1000 PoE+ ports
③RJ Serial Console port

Figure 2 shows the back panel of HPE Aruba JL255A.





JL255A Specification

JL255A Specifications

TypeAruba 2930F 24G PoE+ 4SFP+ Switch
System specifications
I/O ports and slots· 24 RJ-45 autosensing 10/100/1000 PoE+ ports

(IEEE 802.3 Type 10BASE-T, IEEE 802.3u Type 100BASE-TX, IEEE 802.3ab Type 1000BASE-T, IEEE 802.3at PoE+); Duplex: 10BASE-T/100BASETX: half or full 1000BASE-T: full only

· 4 SFP+ 1/10GbE ports; PHY-less

Additional ports and slots1 dual-personality (RJ-45 or USB micro-B) serial console port
Memory and processorDual Core ARM Coretex @ 1016 MHz, 1 GB DDR3 SDRAM

Packet buffer size: 12.38 GB 4.5MB Ingress/7.875MB Egress, 4 GB eMMC

ManagementAruba AirWave Network Management; IMC – Intelligent Management Center

Command-line interface

Web browser

Configuration menu

SNMP manager

Telnet

RMON1

FTP

Out-of-band management (serial RS-232C or micro USB)

Performance specifications



1000 Mb Latency< 3.8 μs (64-byte packets)
10 Gbps Latency< 1.6 μs (64-byte packets)
Throughputup to 95.2 Mp/s
Switching capacity128 Gb/s
Routing table size10000 entries (IPv4), 5000 entries (IPv6)
MAC address table size32768 entries
Physical specifications
Dimensions4.39 x 44.25 x 30.42 cm ( 1.73 x 17.42 x 11.98 in)

1U height

Electrical specifications
80plus.org CertificationSilver
DescriptionN/A
Maximum heat dissipation1601.49 kJ/hr (1518 BTU/hr)
Voltage100 – 127 / 200 – 240 V ac, rated
Current4.9/2.4 A
Maximum power rating445 W
Idle power36.8 W
Frequency50/60 Hz
PoE power370 W PoE+
Environmental specifications
Operating temperature0°C to 45°C (32°F to 113°F)

up to 5000 Feet

– 0C to 40C (32F to 104F) up to 10000 Feet

Operating relative humidity15% to 95% @ 40°C ( 104°F)

noncondensing

Nonoperating/Storage temperature-40°C to 70°C (-40°F to 158°F)

up to 15000 Feet

Nonoperating/Storage temperature15% to 95% @65°C ( 149°F)

noncondensing

AcousticPower: 54.1 dB, Pressure: 40.2 dB
Airflow directionSide-to-side
Safety certifications
SafetyUL 60950-1, 2nd Edition

EN 60950-1:2006 +A11:2009 +A1:2010 +A12:2011+A2:2013

IEC 60950-1:2005 +A1:2009 +A2:2013

CSA 22.2 No. 60950-1-07 2nd

EN 60825-1:2007 / IEC 60825-1:2007 Class 1

EmissionsEN 55022:2010/CISPR 22 Class A

FCC CFR 47 Part 15 Class A

VCCI Class A; ICES-003 Class A

CNS 13438

ImmunityGeneric:EN 55024:2010/CISPR 24

ESDIEC 61000-4-2

RadiatedIEC 61000-4-3

EFT/BurstIEC 61000-4-4

SurgeIEC 61000-4-5

ConductedIEC 61000-4-6

Power frequency magnetic fieldIEC 61000-4-8

Voltage dips and interruptionsIEC 61000-4-11

HarmonicsIEC/EN 61000-3-2

FlickerIEC/EN 61000-3-3
