Description
Yealink CP965 Touch-Sensitive HD IP Conference Phone
Touch-Sensitive HD IP Conference Phone Yealink CP965 is designed for medium and large-sized conference rooms. Based on Android 9.0 system, it is a flagship HD conference phone with powerful voice conferencing features and easy control operation. CP965 adopts a business and introverted design that perfectly matches the calm style of the conference room, but also a acoustic fabric, which is impervious to any accidental liquid spills.
Its fingerprint-proof LCD screen with a clear UI interaction page makes it easy for everyone to control the meeting. CP965 has 13 built-in microphones, providing you with a clear and natural conference call experience. In addition, you can also connect CP965 to your mobile device (such as PC device, smart phone, etc.) via Bluetooth or USB to achieve a variety of UC hybrid meeting modes. CP965 can be connected with 3 CPs in star shape to realize synchronous sound pickup and playback, providing users with an optimum audio experience. CP965 provides you with a new intelligent voice conferencing solution, which is the ideal office assistant for your conference room.
Yealink CP965 Conference Phone Specifications
Audio Features
| Feature | Specification |
|---|
| Audio Quality | Optimal HD audio |
| Noise Reduction | Yealink Noise Proof Technology, Smart Noise Filtering |
| Voice Pickup Range | 13ft (4m) high-quality, 20ft (6m) maximum |
| Microphone Array | Built-in 12-microphone array (360° voice pickup), 1-microphone array for noise reduction |
| Loudspeaker | 56mm diameter, 5W speaker |
| Loudspeaker Frequency | 100-20,000 Hz |
| Loudspeaker Volume | 94 dB at 0.5m peak volume |
| Full-Duplex Speakerphone | With AEC (Acoustic Echo Cancellation) |
| Echo Cancellation Tail Length | Up to 320ms |
| Background Noise Suppression | Yes |
| Codecs Supported | G722, G722.1C, G726, G.729, G.729A, G723, iLBC, PCMU (G.711A), PCMA (G.711μ) |
| DTMF Support | In-band, Out-of-band (RFC 2833), SIP INFO |
| Additional Features | VAD, CNG, PLC, AJB, AGC |
Phone Features
| Feature | Specification |
|---|
| SIP Account | 1 |
| Call Functions | Hold, mute, DND, call recording, hotline |
| Conference Call | 10-way conference call |
| PSTN Calls | Supported via CPN10 |
| Call Management | Redial, call waiting, emergency call, forward, transfer, return, dial plan |
| Ringtone | Selection/import/delete |
| Date & Time | Manual or automatic |
| Volume Adjustment | Yes |
| Bluetooth Pairing | Yes |
| Meeting Features | Create & join meetings, Active Speaker Star connection |
| Device Pairing | Up to four CP965 units (One Master CP, three Slave CP) |
| Network Type | Wired only |
| Expansion | Two expansion microphones per CP965 |
Directory
| Feature | Specification |
|---|
| Local Phonebook | Up to 1000 entries |
| Remote Phonebook | XML/LDAP supported |
| Search Methods | Intelligent search |
| Call History | Dialed, received, missed, forwarded |
| Block List | Yes |
IP-PBX Features
| Feature | Specification |
|---|
| Busy Lamp Field (BLF) | Yes |
| Multicast Paging | Yes |
| Intercom | Yes |
| Anonymous Call & Rejection | Yes |
| Voicemail | Yes |
| Distinctive Ringtone | Yes |
| Call Pickup | Yes |
Display
| Feature | Specification |
|---|
| Screen | 5” 720×1280 capacitive touch screen |
| Buttons | Volume key, Home button |
Interface
| Feature | Specification |
|---|
| Ethernet | 1 x RJ45 10/100M Ethernet port |
| Wireless Connectivity | Built-in Wi-Fi (2.4GHz/5GHz, 802.11a/b/g/n), Built-in Bluetooth 4.2 |
| Power | Power over Ethernet (IEEE 802.3at, Class 4) |
| USB Ports | 1 x USB 2.0 Type-A, 1 x USB 2.0 Type-C |
| Security | 1 x Security slot |
Network & Security
| Feature | Specification |
|---|
| SIP Protocol | SIP v1 (RFC2543), v2 (RFC3261) |
| Redundancy Support | Yes |
| IPv4/IPv6 | Yes |
| NAT Traversal | STUN mode |
| Connection Modes | Proxy mode, peer-to-peer SIP link |
| IP Assignment | Static/DHCP |
| Web Server | HTTP/HTTPS |
| Time Sync | SNTP |
| Network Protocols | UDP/TCP/DNS-SRV (RFC 3263) |
| QoS | 802.1p/Q tagging (VLAN), Layer 3 ToS, DSCP |
| Encryption & Security | SRTP for voice encryption, TLS1.3, HTTPS certificate manager, AES-256 encryption for configuration file, ADB encryption authenticated |
| Authentication | MD5/SHA1/SHA224/SHA256/SHA384/SHA512 |
| VPN Support | OpenVPN, L2TP VPN |
| Wireless Security | WPA2/WPA3 |
| Secure Boot | Yes |
| Additional Protocols | GARP (Generic Attribute Registration Protocol) |
Management
| Feature | Specification |
|---|
| Configuration | Browser, phone, auto-provision, Yealink Device Management Platform |
| Auto Provision | FTP/TFTP/HTTP/HTTPS for mass deployment, PnP |
| Zero-Sp-Touch | TR-069 |
| Reset & Reboot | Yes |
| Debugging | Package tracing export, system log |
Other Physical Features
| Feature | Specification |
|---|
| Color | Black |
| PoE Adapter | External Yealink PoE adapter (Optional) |
| Power Consumption (PoE) | 7.3W-20W |
| Dimensions (WDH) | 328mm x 322mm x 62mm |
| Operating Humidity | 10~90% |
| Operating Temperature | -10 to +45°C (+14 to 113°F) |
| Storage Temperature | -30 to +70°C (-22 to +158°F) |
Package Features
| Feature | Specification |
|---|
| Package Contents | Yealink CP965 IP conference phone, Ethernet Cable (7.5m CAT5E UTP cable), M2×5 screw, Screwdriver, Wireless Microphone CPW65 (Optional), Quick Start Guide, Yealink PoE Adapter YLPOE30 (Optional) |
| Qty/CTN | 5 PCS |
| Net Weight/CTN | 7.964 kg |
| Gross Weight/CTN | 9.02 kg |
| Giftbox Size | 398mm x 384mm x 105mm |
| Carton Dimensions | 552mm x 392mm x 410mm |
